05/2014
6-190
DC SC2020
6.3.22 System_Data (FAX Service)
Version 1.1
General
825-622 Communication Mode when sending (Speed) 0 0: Fall back from maximum ability of
destination machine
1: V27ter 2400
2: V27ter 2400, V27ter 4800
3: V27ter 2400, V27ter 4800, V29
7200, V29 9600
4: V27ter 2400, V27ter 4800, V29
7200, V29 9600
5: V27ter 2400, V27ter 4800, V29
7200, V29 9600, V17 7200, V17 9600,
V17 12000, V17 14400
825-623 Communication Mode when receiving (Speed) 0 0: V27ter+V29+V17
1: V27ter Fall back Mode (only 2400)
2: V27ter (2400,4800)
3: V29 (7200, 9600)
4: V27ter+V29
5: V27ter+V29
825-625 No. of DIS Ignored 0 0~255: 0time~255times
825-626 TSI · CIG Sending Timing 00: AUTO
1: Always send
2: Do not send
825-627 CSI Sending 0 0: Send
1: Do not send
825-628 No. of FTT until Fall Back 0 0: All 2FTT
2: All 2FTT
825-629 TCF Signal Determination Reference 0 0: 1.2sec
1: 1sec
825-630 Sending Cable Equalizer 0 0: 0db (0km)
1: 4db (1.9km)
2: 8db (3.6km)
3: 12db (7.2km)
825-631 Receiving Cable Equalizer If the [DAA_REG731:Complex] value is [1], it will fulfill the
communication performance and needs to be set to
[G3M_RX_CABLE_EQU=4].
(Refer to each country value of current DAA_REG731 and set
the value.)
0 0: 0db (0km)
1: 4db (1.9km)
2: 8db (3.6km)
3: 12db (7.2km)
4: Complex=For 1
825-632 TAP HOLD 00: OFF
1: Do TAP Hold
825-633 EP Tone 0 0: Do not give
1: Give
Table 1 6.3.22 System_Data (FAX Service)
Chain-Link NVM Name Detailed Description OFF/ON Default Value Setting Range
