6.3.22 System_Data (FAX Service)
Version 1.1
825-634 No. of FIF bytes for sending DIS/DTC signal 10 0: 4Byte System
1: 5Byte System
2: 6Byte System
3: 7Byte System
4: 8Byte System
5: 9Byte System
6: 10Byte System
7: 11Byte System
8: 12Byte System
9: 13Byte System
10: 14Byte System (Maximum Ability)
825-635 ECM Ability 1 0: Without Ability
1: With Ability
825-636 No. of ECM · CTC Send 5 0~7: 0time~7times
825-637 RNR Signal Timer 1STEP/1S 65 0~255: 0s~255s
825-638 4800bps EQM Comparison Value 0x0D 0x00~0x7F
825-639 7200bps EQM Comparison Value 0x10 0x00~0x7F
825-640 9600bps EQM Comparison Value 0x07 0x00~0x7F
825-641 1200bps EQM Comparison Value 0x1c 0x00~0x7F
825-642 14400bps EQM Comparison Value 0x24 0x00~0x7F
825-643 TCM7200bps EQM Comparison Value 0x16 0x00~0x7F
825-644 TCM9600bps EQM Comparison Value 0x22 0x00~0x7F
825-645 Symbol Speed Maximum Permissible Value
(Valid only when receiving)
5 0: 2400baund
1: 2743baund (Unsupported)
2: 2800baund
3: 3000baund
4: 3200baund
5: 3429baund
825-646 Maximum Bit Speed 14 1: 2400 bps
2: 4800 bps
3: 7200 bps
4: 9600bps
5: 12000 bps
6: 14400 bps
7: 16800 bps
8: 19200 bps
9: 21600 bps
10: 24000 bps
11: 26400 bps
12: 28800bps
13: 31200bps
14: 33600bps
Table 1 6.3.22 System_Data (FAX Service)
