05/2014
6-192
DC SC2020
6.3.22 System_Data (FAX Service)
Version 1.1
General
825-647 Symbol Speed Enabling Instruction 0x3D 0x00~0x3D
0x01: 2400baund
0x02: 2743baund (Unsupported)
0x04: 2800baund
0x08: 3000baund
0x10: 3200baund
0x20: 3429baund
825-648 Bit Speed Enabling Instruction1 0xff 0x00~0xFF
0x01: 2400 bps
0x02: 4800 bps
0x04: 7200 bps
0x08: 9600 bps
0x10: 12000 bps
0x20: 14400 bps
0x40: 16800 bps
0x80: 19200 bps
825-649 Bit Speed Enabling Instruction2 0x3F 0x00~0x3F
0x01: 21600 bps
0x02: 24000 bps
0x04: 26400 bps
0x08: 28800 bps
0x10: 31200 bps
0x20: 33600 bps
825-650 Control Channel Bit Speed 0 0: 1200bps
1: 2400 bps
825-653 Bit Speed Selection Threshold Value 0x09 0x00 ~ 0xFF
825-655 V8Te Time 11 0~255: 0~25.5S
1Step/100ms
825-656 Timeout Time from V34 Mode (Phase2) to Con-
trol Channel
30 5~255: 5~255 Sec
1Step/1Sec
825-657 Sets whether to move to G3 Mode or not
duringV34_CC_TIMER Timeout
1 0: Prohibit
1: Allowed
825-658 V34 Ability V.34 Ability Setting 1 0: Without Ability
1: With Ability
825-659 ANSam Signal Maximum Sending Time 1STEP/100ms 40 1~255: 0.1s~25.5s
825-660 Time it takes from Line Closing to ANSam Sig-
nal Sending
(1.3secs will be added to the setting value from
the Modem Restriction)
1STEP/100ms 22 22~255: 2.2s~25.5s
825-661 Sending Encoding Method 30: MH
1: MR
2: MMR
3: JBIG
Table 1 6.3.22 System_Data (FAX Service)
Chain-Link NVM Name Detailed Description OFF/ON Default Value Setting Range
To Next Page
