05/2014
6-194
DC SC2020
6.3.22 System_Data (FAX Service)
Version 1.1
General
825-703 External Telephone HOOK Detection Thresh-
old Value 1
Use as External Telephone HOOK Detection Threshold Value
when ONHOOK_LVS_THRESH_HI is [1].
If External Telephone HOOK false detection still occurs even
after changing ONHOOK_LVS_THRESH_HI, change either of
EXTEL_HOOK_THRESH_0~2. When doing so, The Voltage
difference value used as the threshold value shall be decided
by using the measured value of line that problem occurred.
10 0 ~ 255V
825-704 External Telephone HOOK Detection Thresh-
old Value 2
Use as External Telephone HOOK Detection Threshold Value
when ONHOOK_LVS_THRESH_HI is [2].
If External Telephone HOOK false detection still occurs even
after changing ONHOOK_LVS_THRESH_HI, change either of
EXTEL_HOOK_THRESH_0~2. When doing so, The Voltage
difference value used as the threshold value shall be decided
by using the measured value of line that problem occurred.
20 0 ~ 255V
825-705 ETSI standard supported External Telephone
HOOK Detection Supplementary Processing
Enable/Disable Starting the External Telephone Supplemen-
tary Processing
0 0: Disabled
1: Enabled
825-706 ETSI standard supported External Telephone
HOOK Detection Supplementary Processing
Voltage Value that determines the External Telephone OFF-
HOOK of External Telephone Supplementary Processing
15 10, 15, 20(V)
825-707 Voltage Threshold Value used for Line Voltage
Detection
40 10 ~ 50
1Step/1V
825-708 Call Time Lower Limit in Auto Receiving Mode
(FAX only, TEL/FAX, ANS/FAX)
If AUTO_ANSWER_DELAY,
AUTO_ANSWER_TIME_TELFAX, AUTO_ANSWER_RUSU
is setting value or less, make the setting value +100ms.
O 0 0: Disabled
1 to 255sec
825-709 Call Time Upper Limit in Auto Receiving Mode
(FAX only, DRPD)
If AUTO_ANSWER_DELAY is bigger than the setting value,
change it to setting time
O 0 0: Disabled
1 to 255sec
825-710 Forbid Dial Pulse If this is prohibited, even 10PPS/20PPS is instructed for Dial
Type [DIAL_TYPE] it will still operate in PB.
O 0 0: Allow DP20
1: Prohibit
Table 1 6.3.22 System_Data (FAX Service)
Chain-Link NVM Name Detailed Description OFF/ON Default Value Setting Range
