HP PageWide Enterprise Color 556

10. Lift the front of the control panel o of the printer (callout 1), and then slide it toward the front of the
printer (callout 2) to remove it.
Figure 1-204 Remove the control panel
2
1
11. Remove the USB port cover.
Figure 1-205 Remove the USB port cover
ENWW Removal and replacement procedures 159
