12. Remove three screws (callout 1) to release the USB port PCA (callout 2), and then release the cable from
the retainers (callout 3).
Figure 1-206 Remove screws and release the cable
1
2
3
13. Remove two screws (callout 1).
Figure 1-207 Remove two screws
1
