HP PageWide Enterprise Color 556

6. Release two tabs (callout 1) to release the wire guide.
Figure 1-236 Release two tabs
1
7. At the rear of the printer, ex the top cover to the left (callout 1) and then slightly lift it up (callout 2) to
release two tabs.
NOTE: To locate the tabs, see step 3.
Figure 1-237 Release two tabs
2
1
ENWW Removal and replacement procedures 175
