HP PageWide Enterprise Color 556

4. At the front of the printer, slide the cover to the left (callout 1) to engage the tabs and the hooks (callout
2/3).
NOTE: To locate the tabs, see step 3.
Figure 1-361 Engage the cover
2
1
3
5. At the rear of the printer, ex the top cover to the right (callout 1) to engage two tabs (callout 2).
NOTE: To locate the tabs, see step 3.
Figure 1-362 Engage two tabs
2
1
242 Chapter 1 Removal and replacement ENWW
