HP PageWide Enterprise Color 556

Figure 1-730 Locate the control-panel mounting hooks and slots
3
2
1
2. Position the rear edge of the control panel in the SSA chassis (callout 1), and then lower the front of the
assembly down (callout 2).
NOTE: Make sure that the hooks on the SSA chassis are engaged in the slots of the control-panel base
(see step3).
Figure 1-731 Install the control panel
1
2
ENWW Removal and replacement procedures 443
