3. Use the screwdriver provided in the kit to install two screws (callout 1). Connect one HMDI cable and one
connector (callout 2), and then install the USB cable in the holder and retainers (callout 3).
Figure 1-732 Install thumbscrews and connect connectors
4. 586z MFP only: Install the keyboard.
Figure 1-733 Install the keyboard (586z)
444 Chapter 1 Removal and replacement ENWW
