HP PageWide Enterprise Color 556

3. Locate the four hooks on the ISA chassis (callout 1) and the matching slots in the control-panel base
(callout 2). The hooks t into the slots (callout 3) when the assembly is installed.
Figure 1-41 Locate the control-panel mounting hooks and slots
3
2
1
4. Position the rear edge of the control panel in the ISA chassis (callout 1), and then lower the front of the
assembly down (callout 2).
NOTE: Make sure that the hooks on the ISA chassis are engaged in the slots of the control-panel base
(see step3).
Figure 1-42 Install the control panel
1
2
ENWW Removal and replacement procedures 41
