Table 2-7 Numerical parts list (continued)
Part number Description Table and page
G1W39-67936 Cover, lower back scanner control board (586) Covers (586 models)
on page 627
G1W39-67937 Cover, image scanner base (586) Covers (586 models)
on page 627
G1W39-67939 Formatter PCA assembly—China only (586) Internal assemblies on page 629
G1W39-67943 Image scanner (586) kit; includes white backing and retention clips Document feeder and scanner
whole units (586 only)
on page 623
G1W39-67944 Output bin Covers (556 models)
on page 625
G1W39-67944 Output bin Covers (586 models)
on page 627
G1W39-67948 Ship/move kit Internal assemblies on page 629
G1W39-67949 Flap-eject assembly Covers (556 models)
on page 625
G1W39-67949 Flap-eject assembly Covers (586 models)
on page 627
G1W39-67950 Cover, ISS Covers (556 models)
on page 625
G1W39-67950 Cover, ISS Covers (586 models)
on page 627
G1W39-67952 Tray 3 assembly and feeder kit Internal assemblies on page 629
G1W39-67953 Tray 4 assembly and feeder kit Internal assemblies on page 629
G1W39-67954 Tray 5 assembly and feeder kit Internal assemblies on page 629
G1W39-67955 Tray 2 Internal assemblies on page 629
G1W39-67956 Tray 3 (tray only) Internal assemblies on page 629
G1W39-67957 Tray 4 (tray only) Internal assemblies on page 629
G1W39-67958 Tray 5 (tray only) Internal assemblies on page 629
G1W41-67901 Multi-function print mechanism kit (586) Internal assemblies on page 629
G1W41-67902 320 GB hard disk drive (HDD; 586 all; 556xh) Internal assemblies on page 629
G1W41-67903 White backing (586) Document feeder and scanner
whole units (586 only)
on page 623
G1W41-67904 Retention Clip Assembly (586) Document feeder and scanner
whole units (586 only)
on page 623
G1W41-67905 Control panel (586) kit Document feeder and scanner
whole units (586 only)
on page 623
G1W41-67907 Control panel (556) Covers (556 models)
on page 625
636 Chapter 2 Parts and diagrams ENWW
