OPERATION
5. Lift forward end of divider and install bolt (A) and
special stepped washer (B) (step towards divider).
Tighten bolt.
6. Check that divider does not move laterally. Adjust
bolts (C) as required to tighten divider and remove
lateral play when pulling at divid er tip.
7. Close endshield. Refer to 3.2.3 Endshields, page 33.
Figure 3.89: Crop Divider
3.7.13 Crop Divider Rods
Crop divid
er rods are used in conjunction with crop d ividers. T he re movable crop divider rods are most useful
when crop i
s down, but in standing crops using only crop dividers is r ecommended.
Table 3.9
Crop Divider Rods Recommended Use
With Divi
der Rods
Without D
ivider Rods
Alfalfa
Edible beans
Canola
Milo
Flax Rice
Grass seed Soybeans
Lentils
Standi
ng cereal
Lodged cereal
Peas
Soybeans
Suda
ngrass
Winter forage
