OPTIONS AND ATTACHMENTS
6.2 Cutterbar
6.2.1 Cutterbar Wearplate
Available as an attachment, they are recommended for
cutting on the ground where soil adheres to steel.
Bundles by header size:
• 30ft. –MD#B4839
• 35ft. –MD#B4840
• 40ft. –MD#B4841
•45ft.–MD#B5114
Figure 6.5: Cutterbar Wearplate
6.2.2 Knifehead Shield
The shields attach to the endsheets and reduce the
knifehead opening to prevent cut crop, particularly severely
lodged crop, from accumulating over the knifehead, which
could damage the knife drive box and the endsheet.
Order kit according to header size and guard type.
Regular Guards:
• 30 ft. and larger – MD #220101
Stub Guards:
• 30 ft. and larger – MD #220103
Figure 6.6: Knifehead Shield
147695 409 Revision A
