MAINTENANCE AN D SERVICING
5.8 Knife
WARNING
Keep hands clear of the area between guards and
knife at all times.
CAUTION
To avoid persona
l injury, before servicing machine
or opening driv
ecovers,referto5.1 Preparation for
Servicing, pag
e251.
CAUTION
Wear heavy g loves when working around or
handling knives.
Figure 5.8
2: Cutterbar Hazard
5.8.1 Rep l
acing Knife Section
Check daily that knife sections are firmly bolt ed to the knife back and are not worn or broke n. Damaged o r worn
sections leave behind uncut plants. A worn or broken section can be replaced without removing knife from cutterbar.
Coarse serrated sections last longer than fine serrated sections in dirty or sandy conditions.
Fine serrated sections perform better in fine stemmed grasses and plants that contain more fibrou s stems.
147695 299 Revision A
