6 Options and Attachments
The following options and attachments are available for use with your header. Most come with installation
instructions. See your MacDo n Dealer for availab ility and ordering info rmation.
6.1 Reel
6.1.1 Multi-C rop Rapid Reel Conversion Kit
This kit decreases the time required to change the fore-aft
cylinder position on the reel support arm from the normal
operating location to a farther aft location that minimizes
disturbance of the crop. The reel fore-aft cylinders can also
be quickly relocated back to the normal operating position.
MD #B5943
Figure 6
.1: Center Arm – Left and Right Similar
6.1.2 Lo
dgedCropReelFingerKit
The ste
el fingers attach to ends of every other tine bar and
help in
clearing material in heavy, hard-to-cut crops such
as lodg
ed rice.
Each ki
t contains three fingers for the cam end and three
finger
s for the tail end of the reel. Hardware, installation
and ad
justment instructions are included with the kit.
MD #B4
831
Figure 6.2: Lodged Crop Finger
147695 407 Revision A
