HEADER ATTAC HMENT/D ETACH ME NT
4.5.3 CR Feede
rDeflectors
For New Holla nd combin es: Feeder short deflectors have been factory-installed on the adapter to improve feeding
into the feeder house. They may also have been installed as an option on older machines. If necessary, they can
be remove d. Refer to 5.11.3 Replacing Feed Deflectors, page 332.
Long feeder kits are provided for narrow feeder house combines, and can be installed to replace the short
feeder deflectors.
Combine Model Feeder House Size Feeder Kit Size
Part Number
CR970, 9070, 9080,
9090
Wide
Short: 7-7/8 in.
(200 mm)
MD #B5405
CR960, 906
0, 940,
9040
Narrow
Long: 12-1
3/16 in. (325 mm)
MD #B5404
147695 230 Revision A
