MAINTENANCE AND SERVICING
5.6.4 Install
ing Driveline Guard
To install the m ain driveline guards, follow the se steps:
1. Slide guard onto driveline, and line up slo tted lug on
locking ring (A) with arrow (B) on guard.
Figure 5.41: Guard
2. Push guard onto ring until locking ring is visible in
slots (A).
Figure 5.42: Guard
3. Rotat
e rin g (A) clockwise with a screwdriver to lock ring
in gua
rd.
Figure 5.43: Guard
147695 282 Revision A
