Model and Serial Number
Record the mod
el number, serial numb e r, and model year of the head er, c ombine adapte r, and transport/stabilizer
wheel option (
if installed) on the lines below.
NOTE:
Right-hand (RH) and left-hand (LH) designations are determined from the operator’s position, facing forward.
Draper Heade
r
Header Model:
Serial Numb
er:
Year:
The serial
number plate (A) is located beside the knife
drive moto
r on the left-hand endsheet.
Figure 2: Header
Combine Adapter
Adapter
Model:
Serial Number:
Year:
The serial number plate (A) is located on the underside
of the reservoir at the right end.
Figure 3: Adapter
Slow
Speed Transport/Stabilizer Wheel Option
Serial Number:
Yea
r:
The serial number plate (A) is located on the right-hand
axle assembly.
Fi
gure 4: Transport/Stabilizer Option
