OPTIONS AND ATTACHMENTS
6.1.3 PR15 Tin
e Tube Reel Conversion Kit
This kit allows conversion of a six-bat reel to a nine-bat reel.
Order bundles by header size and type:
• 3 0 ft. – Plastic Fingers MD #B5278
16
• 30 ft. – Steel Fingers MD #B5657
• 3 5 ft. – Plastic Fingers MD #B5674
NOTE:
Must orde r a
dditional endshields when converting reel.
6.1.4 Reel Endshie
ld Kit
The steel shields a
ttach to ends of the reel(s) a nd help
in clearing materi
al in heavy, hard-to-cut crops. They are
standard equipme
nt on all, except nine-bat headers. See
your MacDon Deale
r for more information. In stallation and
adjustment instr
uctions are included with the kit.
Figure 6.3: Reel Endshields
6.1.5 Reel Tine Tube Reinforcing Kit
The reel tine tube reinforcing kit is available for five-bat and
six-bat re e ls when cutting e xt re mely h ea vy crops where
high reel loads are experienced.
•5-Bat–MD#B5825
•6-Bat–MD#B5826
Figure 6.4: 5-Ba t Show n – 6-Bat Similar
16. Double-reel units only
147695 408 Revision A
