OPTIONS AND ATTACHMENTS
6.3 Header
6.3.1 Divider Latch Kit
The latches attach to the endsheets. They allow for
quick removal of endsheet divider cones to accommodate
storage and if required, to reduce the transport width of the
header. Installation instructions are included with the kit.
MD #B5607
Figure 6.9
: Div ider Lat c h
6.3.2 Stab
ilizer Wheels
The stabi
lizer wheels help stabilize the header in field
conditio
ns that would otherwise cause the header to
bounce an
d result in uneven cutting height. Installation
and adjus
tment instructions are included with the kit.
Availab
le as an attachment for use with 30-, 35-, 40-, and
45-ft. h
eaders.
MD #C 198
6
Figure 6.10: Stabilizer Wheel
147695
4
11
Revision A
