MacDon FFT FlexDraper FD75 - Disengaging Reel Safety Props

OPERATION
3. At the center reel a rm on double-reel headers, use
handle (A) to move lock r od to inboard po sit ion (B),
engaging pin (C) under prop.
4. Lower reel until safety props contact cylinder mounts
on outer reel arms and pin at center arm.
Figure 3.4: Center Arm Reel Prop
Disengaging Reel Safety Props
1. Raise re
el to maximum height.
2. At oute
r reel arms, move props (A) back inside
reel ar
ms.
Figu
re 3.5: Re e l Arm Safety Pro p
