HEADER ATTA CHMEN T/DETACHMENT
4.6 Challenger, Gleaner, and Massey Ferguson Combines
4.6.1 Attaching Header to Challenger, Gleaner, or
Massey Ferguson Combine
To attach a header to a C hallenger, Gleaner, or Massey
Ferguson combine, co mplete the following steps:
1. Retract lugs (A) at b a
se of feeder house with
lock handle (B).
Figure 4.75: Challenger and Massey Ferguson
Figure 4.76:
Gleaner R and S Series
147695 231 Revision A
