HEADER ATTAC HMENT/D ETACH ME NT
7. Position coupler (A) onto storage p lat e (B) on combine.
Figure 4.69: Combine Coupler
8. Remove electrical connector (A) from adapter.
Figure 4.70: Adapter Connections
9. Connect electrical connector to combine at (A).
Figure 4.71: Combine Couplers
147695 228 Revision A
