MAINTENANCE AND SERVICING
5. Loosen bolt (A) securing idler sprocket (B).
6. Rotateaugerinreversetotakeupslackinlowerstrand
of chain (C).
Figure 5.64: Auger Drive
7. Push idler sprocket (A) down to eliminate remaining
slack in upper strands (B).
8. Rotate auger back and forth to check slack and repeat
above step, if necessary. A slight amount of slack
is acceptable.
NOTE:
Do not use excessive force on idler sprocket (A)
to tighten chain (B).
9. Torque idler bolt (C) to 121–134 ft·lbf (163–181 N·m).
Figure 5.65: Auger Drive
147695 292 Revision A
