MAINTENANCE AN D SERVICING
8. Position aft deflector (C) as shown and install
three 3/8 in. x 3/4 carriage bolts (B) and lock nuts.
Orientation of bolts not important.
9. Install two Torx
®
head screws (A) and lock nuts with
heads facing down.
10. Tighten all fasteners.
11. Repeat above steps for opposite end.
Figure 5.189: Aft Deflector
147695 349 Revision A
