5. PARAMETERS
5 - 25
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PA11
TLP
Forward
rotation
torque limit
You can limit the torque generated by the servo motor.
When torque is output with the analog monitor output, the setting of [Pr. PA11
Forward rotation torque limit/] or [Pr. PA12 Reverse rotation torque limit/], whichever
is larger, will be the maximum output voltage (8 V).
Set the parameter on the assumption that the rated torque or continuous thrust is
100.0 [%]. Set the parameter for limiting the torque of the servo motor in the CCW
power running or CW regeneration, or for limiting the thrust of the linear servo motor
in the positive direction power running or negative direction regeneration. Set this
parameter to "0.0" to generate no torque .
The polarity of the torque limit can be changed depending on the setting values of
[Pr. PA14 Rotation direction selection/] and [Pr. PC29 POL reflection selection at
torque mode].
This parameter corresponds to "Positive torque limit value (Index: 60E0h)". When
this parameter is mapped for the PDO communication, the value written with Setup
software (MR Configurator2
TM
) is overwritten with the upper side. Thus, do not write
a value with Setup software (MR Configurator2
TM
).
Setting range: 0.0 to 1000.0
1000.0
[%]
You can limit the torque generated by the servo motor.
When torque is output with the analog monitor output, the setting of [Pr. PA11
Forward rotation torque limit/] or [Pr. PA12 Reverse rotation torque limit/], whichever
is larger, will be the maximum output voltage (8 V).
Set the parameter on the assumption that the rated torque or continuous thrust is
100.0 [%]. Set the parameter for limiting the torque of the servo motor in the CCW
power running or CW regeneration, or for limiting the thrust of the linear servo motor
in the positive direction power running or negative direction regeneration. Set this
parameter to "0.0" to generate no torque .
The polarity of the torque limit can be changed depending on the setting values of
[Pr. PA14 Rotation direction selection/] and [Pr. PC29 POL reflection selection at
torque mode].
This parameter corresponds to "Positive torque limit value (Class ID: 64h, Ins ID:
60E0h, Attr ID: 0)". When this parameter is mapped for the I/O communication, the
value written with Setup software (MR Configurator2
TM
) is overwritten with the upper
side. Thus, do not write a value with Setup software (MR Configurator2
TM
).
Setting range: 0.0 to 1000.0
1000.0
[%]
You can limit the torque generated by the servo motor.
When torque is output with the analog monitor output, the setting of [Pr. PA11
Forward rotation torque limit/] or [Pr. PA12 Reverse rotation torque limit/], whichever
is larger, will be the maximum output voltage (8 V).
Set the parameter on the assumption that the rated torque or continuous thrust is
100.0 [%]. Set the parameter for limiting the torque of the servo motor in the CCW
power running or CW regeneration, or for limiting the thrust of the linear servo motor
in the positive direction power running or negative direction regeneration. Set this
parameter to "0.0" to generate no torque .
The polarity of the torque limit can be changed depending on the setting values of
[Pr. PA14 Rotation direction selection/] and [Pr. PC29 POL reflection selection at
torque mode].
This parameter corresponds to "Positive torque limit value (PNU: 24800, Sub: 0)".
When this parameter is mapped for the Process Data communication, the value
written with Setup software (MR Configurator2
TM
) is overwritten with the upper side.
Thus, do not write a value with Setup software (MR Configurator2
TM
).
Setting range: 0.0 to 1000.0
1000.0
[%]
