Note: The CPOL, CPHA and LBCL bits should not be written while the transmitter is enabled.
35.8.4 USART control register 3 (USART_CR3)
Address offset: 0x08
Reset value: 0x0000 0000
Bit 5 LBDL: LIN break detection length
This bit is for selection between 11 bit or 10 bit break detection.
0: 10-bit break detection
1: 11-bit break detection
This bit can only be written when the USART is disabled (UE = 0).
Note: If LIN mode is not supported, this bit is reserved and must be kept at reset value. Refer to
Section 35.4: USART implementation on page 1116.
Bit 4 ADDM7: 7-bit address detection/4-bit address detection
This bit is for selection between 4-bit address detection or 7-bit address detection.
0: 4-bit address detection
1: 7-bit address detection (in 8-bit data mode)
This bit can only be written when the USART is disabled (UE = 0)
Note: In 7-bit and 9-bit data modes, the address detection is done on 6-bit and 8-bit address
(ADD[5:0] and ADD[7:0]) respectively.
Bit 3 DIS_NSS: NSS pin enable
When the DIS_NSS bit is set, the NSS pin input is ignored.
0: SPI slave selection depends on NSS input pin.
1: SPI slave is always selected and NSS input pin is ignored.
Note: When SPI slave mode is not supported, this bit is reserved and must be kept at reset value.
Refer to Section 35.4: USART implementation on page 1116.
Bits 2:1 Reserved, must be kept at reset value.
Bit 0 SLVEN: Synchronous Slave mode enable
When the SLVEN bit is set, the synchronous slave mode is enabled.
0: Slave mode disabled.
1: Slave mode enabled.
Note: When SPI slave mode is not supported, this bit is reserved and must be kept at reset value.
Refer to Section 35.4: USART implementation on page 1116.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TXFTCFG[2:0]
RXF
TIE
RXFTCFG[2:0]
TCBG
TIE
TXFTIE WUFIE WUS[1:0] SCARCNT[2:0] Res.
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
DEP DEM DDRE
OVR
DIS
ONE
BIT
CTSIE CTSE RTSE DMAT DMAR SCEN NACK
HD
SEL
IRLP IREN EIE
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
