RM0453 Rev 5 1309/1450
RM0453 Serial peripheral interface / integrated interchip sound (SPI/I2S)
1311
37.9.9 SPIx_I2S prescaler register (SPIx_I2SPR)
Address offset: 0x20
Reset value: 0x0002
Bit 3 CKPOL: Inactive state clock polarity
0: I2S clock inactive state is low level
1: I2S clock inactive state is high level
Note: For correct operation, this bit should be configured when the I2S is disabled.
It is not used in SPI mode.
The bit CKPOL does not affect the CK edge sensitivity used to receive or transmit the SD and
WS signals.
Bits 2:1 DATLEN[1:0]: Data length to be transferred
00: 16-bit data length
01: 24-bit data length
10: 32-bit data length
11: Not allowed
Note: For correct operation, these bits should be configured when the I2S is disabled.
They are not used in SPI mode.
Bit 0 CHLEN: Channel length (number of bits per audio channel)
0: 16-bit wide
1: 32-bit wide
The bit write operation has a meaning only if DATLEN = 00 otherwise the channel length is fixed to
32-bit by hardware whatever the value filled in.
Note: For correct operation, this bit should be configured when the I2S is disabled.
It is not used in SPI mode.
151413121110 9 876543210
Res. Res. Res. Res. Res. Res. MCKOE ODD I2SDIV[7:0]
rw rw rw rw rw rw rw rw rw rw
Bits 15:10 Reserved, must be kept at reset value.
Bit 9 MCKOE: Master clock output enable
0: Master clock output is disabled
1: Master clock output is enabled
Note: This bit should be configured when the I2S is disabled. It is used only when the I2S is in
master mode.
It is not used in SPI mode.
Bit 8 ODD: Odd factor for the prescaler
0: Real divider value is = I2SDIV *2
1: Real divider value is = (I2SDIV * 2) + 1
Refer to Section 37.7.3 on page 1289.
Note: This bit should be configured when the I2S is disabled. It is used only when the I2S is in
master mode.
It is not used in SPI mode.
