RM0453 Rev 5 1363/1450
RM0453 Debug support (DBG)
1435
CTI authentication status register (CTI_AUTHSTATR)
Address offset: 0xFB8
Reset value: 0x0000 000A
CTI device configuration register (CTI_DEVIDR)
Address offset: 0xFC8
Reset value: 0x0004 0800
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. SNID[1:0] SID[1:0] NSNID[1:0] NSID[1:0]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:6 SNID[1:0]: security level for secure non-invasive debug
0x0: Not implemented
Bits 5:4 SID[1:0]: security level for secure invasive debug
0x0: Not implemented
Bits 3:2 NSNID[1:0]: security level for non-secure non-invasive debug
0x2: Disabled
0x3: Enabled
Bits 1:0 NSID[1:0]: security level for non-secure invasive debug
0x2: Disabled
0x3: Enabled
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. NUMCH[3:0]
rrrr
1514131211109876543210
NUMTRIG[7:0] Res. Res. Res. EXTMUXNUM[4:0]
rrrrrr r r r r r r r
Bits 31:20 Reserved, must be kept at reset value.
Bits 19:16 NUMCH[3:0]: number of ECT channels
0x4: 4 channels
Bits 15:8 NUMTRIG[7:0]: number of ECT triggers
0x8: 8 trigger inputs and 8 trigger outputs
Bits 7:5 Reserved, must be kept at reset value.
Bits 4:0 EXTMUXNUM[4:0]: number of trigger input/output multiplexers
0x0: None
