CTI CoreSight peripheral identity register 0 (CTI_PIDR0)
Address offset: 0xFE0
Reset value: 0x0000 0006
CTI CoreSight peripheral identity register 1 (CTI_PIDR1)
Address offset: 0xFE4
Reset value: 0x0000 00B9
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. PARTNUM[7:0]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 PARTNUM[7:0]: part number bits [7:0]
0x06: CTI part number
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. JEP106ID[3:0] PARTNUM[11:8]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:4 JEP106ID[3:0]: JEP106 identity code bits [3:0]
0xB: Arm
®
JEDEC code
Bits 3:0 PARTNUM[11:8]: part number bits [11:8]
0x9: CTI part number
