RM0453 Rev 5 311/1450
RM0453 Reset and clock control (RCC)
371
7.4.3 RCC clock configuration register (RCC_CFGR)
Address offset: 0x008
Reset value: 0x0007 0000
(after POR reset and after wake-up from Standby)
Access: 0 ≤ wait state ≤ 2, word, half-word and byte access
One or two wait states inserted only if the access occurs during clock source switch.
From 0 to 15 wait states inserted if the access occurs when the APB or AHB prescalers
values update is ongoing.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. MCOPRE[2:0] MCOSEL[3:0] Res. Res. Res. Res. Res.
PPRE
2F
PPRE
1F
HPREF
rw rw rw rw rw rw rw r r r
1514131211109 8 7 65432 1 0
STOP
WUCK
Res. PPRE2[2:0] PPRE1[2:0] HPRE[3:0] SWS[1:0] SW[1:0]
rw rw rw rw rw rw rw rw rw rw rw r r rw rw
Bit 31 Reserved, must be kept at reset value.
Bits 30:28 MCOPRE[2:0]: Microcontroller clock output prescaler
These bits are set and cleared by software.
It is highly recommended to change this prescaler before MCO output is enabled.
000: MCO divided by 1
001: MCO divided by 2
010: MCO divided by 4
011: MCO divided by 8
100: MCO divided by 16
Others: not allowed
Bits 27:24 MCOSEL[3:0]: Microcontroller clock output selection
These bits are set and cleared by software.
0000: MCO output disabled, no clock on MCO
0001: SYSCLK system clock selected
0010: MSI clock selected.
0011: HSI16 clock selected.
0100: HSE32 clock selected (after stabilization)
0101: Main PLLRCLK clock selected
0110: LSI clock selected
1000: LSE clock selected
1101: Main PLLPCLK clock selected
1110: Main PLLQCLK clock selected
Others: reserved
Note: This clock output may have some truncated cycles at startup, entering and wake-up
from low-power modes, or during MCO clock source switching.
Bits 23:19 Reserved, must be kept at reset value.
