RM0453 Rev 5 889/1450
RM0453 General-purpose timer (TIM2)
892
26.4.24 TIM2 timer input selection register (TIM2_TISEL)
Address offset: 0x68
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. ETRSEL[3:2]
rw rw
1514131211109876543210
ETRSEL[1:0] Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
rw rw
Bits 31:18 Reserved, must be kept at reset value.
Bits 17:14 ETRSEL[3:0]: ETR source selection
These bits select the ETR input source.
0000: GPIO or LSE internal clock, as per ETR_RMP bit in TIM2_OR1
0001: COMP1
0010: COMP2
Others: Reserved
Bits 13:0 Reserved, must be kept at reset value.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. TI2SEL[3:0] Res. Res. Res. Res. TI1SEL[3:0]
rw rw rw rw rw rw rw rw
Bits 31:12 Reserved, must be kept at reset value.
Bits 11:8 TI2SEL[3:0]: TI2[0] to TI2[15] input selection
These bits select the TI2[0] to TI2[15] input source.
0000: TIM2_CH2 input
Others: Reserved
Bits 7:4 Reserved, must be kept at reset value.
Bits 3:0 TI1SEL[3:0]: TI1[0] to TI1[15] input selection
These bits select the TI1[0] to TI1[15] input source.
0000: TIM2_CH1 input
Others: Reserved
