Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 4: Sourcing and measuring
2601B-PULSE-901-01A April 2020 4-59
Digits
The display resolution of the measured reading depends on the DIGITS setting. The default display
resolution setting is 6.5 digits. The DIGITS setting selects display resolution for all measurement
functions.
The DIGITS setting has no effect on the format of readings returned by a print() command over a
remote interface. For information to adjust the format of remote interface readings, see
format.asciiprecision (on page 11-89).
The number of displayed digits does not affect accuracy or speed. Accuracy and speed are controlled
by the SPEED setting (see Speed (on page 4-60)).
Setting display resolution from the front panel
To set the display resolution, press the DIGITS key until the correct number of digits is displayed.
Available display resolutions are 4.5, 5.5, and 6.5 digits.
Setting display resolution from a remote interface
Digits commands
The following table summarizes use of the display.smua.digits command. See the TSP
command reference (on page 11-1) for more information.
display.smua.digits = display.DIGITS_4_5
Set display to 4.5 digits.
display.smua.digits = display.DIGITS_5_5
Set display to 5.5 digits.
display.smua.digits = display.DIGITS_6_5
Set display to 6.5 digits.
Digits programming example
-- Select 5.5 digits.
display.smua.digits = display.DIGITS_5_5
