Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference

2601B-PULSE-901-01A April 2020 11-119

Example

print(lan.linktimeout)

Outputs the present LAN link timeout setting.

Also see

lan.autoconnect (on page 11-110)

lan.restoredefaults() (on page 11-121)

lan.lxidomain

This attribute contains the LXI domain.

Type

TSP-Link accessible

Affected by

Where saved

Default value

Attribute (RW)

Yes

LAN restore defaults

Nonvolatile memory

Usage

domain = lan.lxidomain

lan.lxidomain = domain

domain

The LXI domain number (0 to 255)

Details

This attribute sets the LXI domain number.

All outgoing LXI packets are generated with this domain number. All inbound LXI packets are ignored

unless they have this domain number.

Example

print(lan.lxidomain)

Displays the LXI domain.

Also see

None
