Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-311
Bit
Value and description
B0
Not used
B1
status.operation.sweeping.SMUA
Set bit indicates that SMU A is sweeping.
Bit B1 decimal value: 2
Binary value: 0000 0010
B2 to B15
Not used
As an example, to set bit B1 of the operation status sweeping summary enable register, set
status.operation.sweeping.enable = status.operation.sweeping.SMUA.
In addition to the above constants, operationRegister can be set to 2, the decimal value of Bit 1.
Example
status.operation.sweeping.enable = status.operation.sweeping.SMUA
Uses a constant to set the SMUA bit of the operation status sweeping summary enable register.
Also see
Operation Status Registers (on page 15-8)
status.operation.* (on page 11-281)
status.operation.trigger_overrun.*
This attribute contains the operation status trigger overrun summary register set.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
31,746 (All bits set)
Usage
operationRegister = status.operation.trigger_overrun.condition
operationRegister = status.operation.trigger_overrun.enable
operationRegister = status.operation.trigger_overrun.event
operationRegister = status.operation.trigger_overrun.ntr
operationRegister = status.operation.trigger_overrun.ptr
status.operation.trigger_overrun.enable = operationRegister
status.operation.trigger_overrun.ntr = operationRegister
status.operation.trigger_overrun.ptr = operationRegister
operationRegister
The status of the operation status trigger overrun summary register; a zero (0)
indicates no bits set (also send 0 to clear all bits); other values indicate various
bit settings
