Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-237
smua.source.sink
This attribute turns sink mode on or off.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
SMU reset
Instrument reset
Recall setup
Saved setup
0 (smua.DISABLE)
Usage
sinkMode = smua.source.sink
smua.source.sink = sinkMode
sinkMode
Sets the sink mode on or off; set to one of the following values:
▪ 0 or smua.DISABLE: Turns off sink mode
▪ 1 or smua.ENABLE: Turns on sink mode
Details
This attribute enables or disables sink mode. When sink mode is enabled, it reduces the source limit
inaccuracy that occurs when operating in quadrants II and IV (quadrants I and III will show this source
limit inaccuracy).
Example
smua.source.sink = smua.ENABLE
Enables sink mode.
Also see
Source or sink (on page 7-6)
smua.trigger.arm.count
This attribute sets the arm count in the trigger model.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
SMU reset
Instrument reset
Recall setup
Not saved
1
Usage
triggerArmCount = smua.trigger.arm.count
smua.trigger.arm.count = triggerArmCount
triggerArmCount
The arm count in the trigger model
Details
During a sweep, the SMU iterates through the arm layer of the trigger model this many times. After
performing this many iterations, the SMU returns to an idle state.
If this count is set to zero, the SMU stays in the trigger model indefinitely until aborted.
