Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-377
Example
triggered = tsplink.trigger[3].wait(10)
print(triggered)
Waits up to 10 seconds for a trigger on
TSP-Link
®
line 3.
If false is returned, no trigger was detected
during the 10-second timeout.
If true is returned, a trigger was detected.
Also see
tsplink.trigger[N].clear() (on page 11-370)
tsplink.writebit()
This function sets a TSP-Link trigger line high or low.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
tsplink.writebit(N, data)
N
The trigger line (1 to 3)
data
The value to write to the bit:
▪ Low: 0
▪ High: 1
Details
Use tsplink.writebit() and tsplink.writeport() to control the output state of the trigger
line when trigger operation is set to tsplink.TRIG_BYPASS.
If the output line is write-protected by the tsplink.writeprotect attribute, this command
is ignored.
The reset function does not affect the present states of the TSP-Link trigger lines.
Example
tsplink.writebit(3, 0)
Sets trigger line 3 low (0).
Also see
tsplink.readbit() (on page 11-367)
tsplink.readport() (on page 11-367)
tsplink.writeport() (on page 11-378)
tsplink.writeprotect (on page 11-378)
