Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-310 2601B-PULSE-901-01A April 2020
Example 2
status.operation.remote.enable = 2050
Uses the decimal value to set bits B1 and B11 of the operation status remote summary enable register.
Also see
Operation Status Registers (on page 15-8)
status.operation.* (on page 11-281)
status.operation.sweeping.*
This attribute contains the operation status sweeping summary register set.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
2 (All bits set)
Usage
operationRegister = status.operation.sweeping.condition
operationRegister = status.operation.sweeping.enable
operationRegister = status.operation.sweeping.event
operationRegister = status.operation.sweeping.ntr
operationRegister = status.operation.sweeping.ptr
status.operation.sweeping.enable = operationRegister
status.operation.sweeping.ntr = operationRegister
status.operation.sweeping.ptr = operationRegister
operationRegister
The status of the operation status sweeping summary register; a zero (0) indicates
no bits set (also send 0 to clear all bits); other values indicate various bit settings
Details
These attributes are used to read or write to the operation status sweeping summary registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 15-1) and Enable and transition registers (on page 15-19). The individual bits of
this register are defined in the following table.
