Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-249
Example
smua.trigger.measure.v(smua.nvbuffer1)
smua.trigger.measure.action = smua.ENABLE
Configure sweep voltage measurements.
Enable voltage measurements during the sweep.
Also see
bufferVar.collectsourcevalues (on page 11-23)
smua.trigger.autoclear (on page 11-240)
smua.trigger.measure.Y() (on page 11-251)
Triggering (on page 6-1)
smua.trigger.measure.set()
This function sets the measurement event detector to the detected state.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
smua.trigger.measure.set()
Details
This function is useful whenever you want the SMU to continue operation without waiting for a
programmed trigger event. When called, this function immediately satisfies the event detector,
allowing the SMU to continue through the trigger model.
For example, you might use this function to have the SMU immediately perform an action the first
time through the trigger model, even if a programmed trigger event does not occur.
If the event detectors are configured to clear automatically because the smua.trigger.autoclear
attribute is set to smua.ENABLE, make sure that smua.trigger.measure.set() is issued after
the SMU has entered the trigger layer. This function can also be used to start actions on the SMU in
case of a missed trigger event.
The SMU automatically clears all event detectors when the smua.trigger.initiate() function is
executed. This function should be called after the sweep is initiated.
Example
smua.trigger.measure.set()
Sets the measure event detector.
Also see
smua.trigger.arm.set() (on page 11-238)
smua.trigger.autoclear (on page 11-240)
smua.trigger.endpulse.set() (on page 11-243)
smua.trigger.source.set() (on page 11-258)
