Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-130 2601B-PULSE-901-01A April 2020
Details
The trigger event detector enters the detected state when an event is detected. This function clears a
trigger event detector and discards the history of the trigger packet.
This function clears all overruns associated with this LAN trigger.
Example
lan.trigger[5].clear()
Clears the event detector with LAN packet 5.
Also see
lan.trigger[N].assert() (on page 11-129)
lan.trigger[N].overrun (on page 11-134)
lan.trigger[N].stimulus (on page 11-136)
lan.trigger[N].wait() (on page 11-137)
lan.trigger[N].connect()
This function prepares the event generator for outgoing trigger events.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
lan.trigger[N].connect()
N
The LAN event number (1 to 8)
Details
This command prepares the event generator to send event messages. For TCP connections, this
opens the TCP connection.
The event generator automatically disconnects when either the protocol or IP address for this event is
changed.
Example
lan.trigger[1].protocol = lan.MULTICAST
lan.trigger[1].connect()
lan.trigger[1].assert()
Set the protocol for LAN trigger 1 to be
multicast when sending LAN triggers. Then,
after connecting the LAN trigger, send a
message on LAN trigger 1 by asserting it.
Also see
lan.trigger[N].assert() (on page 11-129)
lan.trigger[N].ipaddress (on page 11-132)
lan.trigger[N].overrun (on page 11-134)
lan.trigger[N].protocol (on page 11-135)
lan.trigger[N].stimulus (on page 11-136)
lan.trigger[N].wait() (on page 11-137)
