Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-331
Example 2
-- decimal 17 = binary 0001 0001
standardRegister = 17
status.standard.enable = standardRegister
Uses the decimal value to set the OPC and EXE bits of the standard event status enable register.
Also see
Standard Event Register (on page 15-21)
status.system.*
These attributes manage the TSP-Link
®
system summary register of the status model for nodes 1 through 14.
Usage
enableRegister = status.system.condition
enableRegister = status.system.enable
enableRegister = status.system.event
enableRegister = status.system.ntr
enableRegister = status.system.ptr
status.system.enable = enableRegister
status.system.ntr = enableRegister
status.system.ptr = enableRegister
The status of the system summary register; a zero (0) indicates no bits set; other
values indicate various bit settings
Details
In an expanded system (TSP-Link), these attributes are used to read or write to the system summary
registers. They are set using a constant or a numeric value but are returned as a numeric value. The
binary equivalent of the value indicates which register bits are set. In the binary equivalent, the least
significant bit is bit B0, and the most significant bit is bit B15. For example, if a value of
1.29000e+02 (which is 129) is read as the value of the condition register, the binary equivalent is
0000 0000 1000 0001. This value indicates that bit B0 and bit B7 are set.
* Least significant bit
** Most significant bit
