Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-340 2601B-PULSE-901-01A April 2020
status.system5.*
These attributes manage the TSP-Link
®
system summary register of the status model for nodes 57 through 64.
Usage
enableRegister = status.system5.condition
enableRegister = status.system5.enable
enableRegister = status.system5.event
enableRegister = status.system5.ntr
enableRegister = status.system5.ptr
status.system5.enable = enableRegister
status.system5.ntr = enableRegister
status.system5.ptr = enableRegister
The status of the system summary 5 register; a zero (0) indicates no bits set; other
values indicate various bit settings
Details
In an expanded system (TSP-Link), these attributes are used to read or write to the system summary
registers. They are set using a constant or a numeric value, but are returned as a numeric value. The
binary equivalent of the value indicates which register bits are set. In the binary equivalent, the least
significant bit is bit B0, and the most significant bit is bit B15. For example, if a value of
1.30000e+02 (which is 130) is read as the value of the condition register, the binary equivalent is
0000 0000 1000 0010. This value indicates that bit B1 and bit B7 are set.
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 15-1) and Enable and transition registers (on page 15-19). The individual bits of
this register are defined in the following table.
