Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-204 2601B-PULSE-901-01A April 2020
Also see
Range (on page 4-54)
reset() (on page 11-156)
setup.recall() (on page 11-175)
smua.measure.autorangeY (on page 11-194)
smua.reset() (on page 11-222)
smua.measure.nplc
This command sets the integration aperture for measurements when the pulser is disabled.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
Instrument reset
SMU reset
Recall setup
Saved setup
1.0
Usage
nplc = smua.measure.nplc
smua.measure.nplc = nplc
nplc
The integration aperture; set from 0.001 to 25
Details
This attribute controls the integration aperture for the analog-to-digital converter (ADC) that is used
when the pulser is disabled.
The integration aperture is based on the number of power line cycles (NPLC), where 1 PLC for 60 Hz
is 16.67 ms (1/60) and 1 PLC for 50 Hz is 20 ms (1/50).
Example
smua.measure.nplc = 0.5
Sets the integration time to 0.5.
Also see
Speed (on page 4-60)
reset() (on page 11-156)
setup.recall() (on page 11-175)
smua.pulser.measure.aperture (on page 11-213)
smua.reset() (on page 11-222)
