Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-281
status.operation.*
These attributes manage the operation status register set of the status model.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
31,769 (All bits set)
Usage
operationRegister = status.operation.condition
operationRegister = status.operation.enable
operationRegister = status.operation.event
operationRegister = status.operation.ntr
operationRegister = status.operation.ptr
status.operation.enable = operationRegister
status.operation.ntr = operationRegister
status.operation.ptr = operationRegister
operationRegister
The status of the operation status register; a zero (0) indicates no bits set (also send
0 to clear all bits); other values indicate various bit settings
Details
These attributes read or write the operation status registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15. For example, if a value of 2.04800e+04 (which is 20,480) is read as the value of the
condition register, the binary equivalent is 0101 0000 0000 0000. This value indicates that bit B14
(PROGRAM_RUNNING) and bit B12 (USER) are set.
B15
B14
B13
B12
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
B0
**
>
>
>
>
>
>
>
>
>
>
>
>
>
>
*
0
1
0
1
0
0
0
0
0
0
0
0
0
0
0
0
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set
contents (on page 15-1) and Enable and transition registers (on page 15-19). The individual bits of
this register are defined in the following table.
Bit
Value and description
B0
status.operation.CALIBRATING
status.operation.CAL
Set bit indicates that the summary bit of the status.operation.calibrating register has
been set.
Bit B0 decimal value: 1
B1 to B2
Not used
