Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 7: Theory of operation
2601B-PULSE-901-01A April 2020 7-13
Source-measure capabilities
The following table lists the source and measure limits for the voltage and current functions.
The maximum power is 40.4 W per channel.
Source-measure capabilities
Voltage range
Source
Measure
100 mV
±101 mV
±102 mV
1 V
±1.01 V
±1.02 V
6 V
±6.06 V
±6.12 V
40 V
±40.4 V
±40.8 V
Current ranges
100 nA
±101 nA
±102 nA
1 µA
±1.01 µA
±1.02 µA
10 µA
±10.1 µA
±10.2 µA
100 µA
±101 µA
±102 µA
1 mA
±1.01 mA
±1.02 mA
10 mA
±10.1 mA
±10.2 mA
100 mA
±101 mA
±102 mA
1 A
±1.01 A
±1.02 A
3 A
±3.03 A
±3.06 A
10 A (only available in pulse mode)
±10.1 A
±10 A
Pulser capabilities
The following table lists the pulser voltage and current ranges.
Voltage range
Source
Measure
5 V
Not applicable
5.1 V
10 V
Not applicable
10.2 V
Current ranges
1 A
±1.01 A
±1.02 A
5 A
±5.05 A
±5.1 A
10 A
±10.1 A
±10.2 A
250 mA (DC bias)
±250 mA
Selected pulse measure range
The 2601B-PULSE can sustain a measurement speed of 33,000, as determined by:
(Pulse rate per second) + (Measurements per second  Filter count) < 33000
If this rate is exceeded, the instrument may not be able to sustain the sweep.
