Section 9: Introduction to TSP operation Model 2601B-PULSE System SourceMeter Instrument Reference Manual
9-20 2601B-PULSE-901-01A April 2020
A factory script is similar to a user script, except a factory script is created by Keithley Instruments at
the factory and is permanently stored in nonvolatile memory. The differences between a user script
and a factory script include the following:
• A factory script cannot be deleted from nonvolatile memory.
• The script listing for a factory script can be retrieved and modified, but it is then treated as a user
script. A user script cannot be saved as a factory script.
• Factory scripts are not stored in global variables. The only references to factory scripts are in the
script.factory.scripts attribute.
• The script.factory.catalog() function returns an iterator that can be used in a for loop
to iterate over all the factory scripts.
Example
To retrieve the catalog listing for factory scripts, send:
for name in script.factory.catalog() do print(name) end
Running a factory script
Use either of the following commands to run a factory script:
script.factory.scripts.name()
script.factory.scripts.name.run()
Where: name is the name of the factory script.
Example:
Run the factory script named KISweep.
script.factory.scripts.KISweep()
Running a factory script function from the front-panel controls
1. Press the LOAD key.
2. Select FACTORY.
3. Select the function to run and press the ENTER key or navigation wheel .
4. Press the RUN key.
5. Follow the prompts on the front panel to run the script.
