Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-259
Details
This function sets the source event detector to the detected state.
The SMU automatically clears all event detectors when the smua.trigger.initiate() function is
executed. This function should be called after the sweep is initiated. If the event detectors are
configured to clear automatically because the smua.trigger.autoclear attribute is set to
smua.ENABLE, make sure that smua.trigger.source.set() is issued after the SMU has
entered the trigger layer.
Example
reset()
smua.trigger.source.listv({5})
smua.trigger.source.stimulus = display.trigger.EVENT_ID
smua.source.output = smua.OUTPUT_ON
smua.trigger.initiate()
delay(1)
-- Continue even if the display trigger key was not pressed.
smua.trigger.source.set()
waitcomplete()
Sets the source event detector.
Also see
smua.trigger.arm.set() (on page 11-238)
smua.trigger.autoclear (on page 11-240)
smua.trigger.endpulse.set() (on page 11-243)
smua.trigger.initiate() (on page 11-247)
smua.trigger.measure.set() (on page 11-249)
Triggering (on page 6-1)
smua.trigger.source.stimulus
This attribute defines which event causes the source event detector to enter the detected state.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute (RW)
Yes
SMU reset
Instrument reset
Recall setup
Not saved
0
Usage
eventID = smua.trigger.source.stimulus
smua.trigger.source.stimulus = eventID
eventID
Set to the event that triggers the end-pulse source off action
