Tektronix Keithley 2601B-PULSE Reference Manual

Model 2601B-PULSE System SourceMeter Instrument Reference Manual Section 11: TSP command reference
2601B-PULSE-901-01A April 2020 11-391
Details
This function associates the string value with the string name and stores this key-value pair in
nonvolatile memory.
Use the userstring.get() function to retrieve the value associated with the specified name.
You can use the userstring functions to store custom, instrument-specific information in the
instrument, such as department number, asset number, or manufacturing plant location.
Example
userstring.add("assetnumber", "236")
userstring.add("product", "Widgets")
userstring.add("contact", "John Doe")
for name in userstring.catalog() do
print(name .. " = " ..
userstring.get(name))
end
Stores user-defined strings in nonvolatile
memory and recalls them from the
instrument using a for loop.
Example output:
assetnumber = 236
contact = John Doe
product = Widgets
Also see
userstring.catalog() (on page 11-391)
userstring.delete() (on page 11-392)
userstring.get() (on page 11-393)
userstring.catalog()
This function creates an iterator for the user-defined string catalog.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
No
Usage
for name in userstring.catalog() do body end
name
The name of the string; the key of the key-value pair
body
Code to execute in the body of the for loop
Details
The catalog provides access for user-defined string pairs, allowing you to manipulate all the key-value
pairs in nonvolatile memory. The entries are enumerated in no particular order.
Example 1
for name in userstring.catalog() do
userstring.delete(name)
end
Deletes all user-defined strings in nonvolatile
memory.
