Tektronix Keithley 2601B-PULSE Reference Manual

Section 11: TSP command reference Model 2601B-PULSE System SourceMeter Instrument Reference Manual
11-268 2601B-PULSE-901-01A April 2020
Bit
Value and description
B0
Not used
B1
status.measurement.buffer_available.SMUA
Set bit indicates that there is at least one reading stored in either or both of the dedicated
reading buffers.
Bit B1 decimal value: 2
Binary value: 0000 0010
B2 to B15
Not used
As an example, to set bit B1 of the measurement event buffer available summary enable register, set
status.measurement.buffer_available.enable =
status.measurement.buffer_available.SMUA.
In addition to the above constants, measurementRegister can be set to the decimal equivalent of
the bit to set.
Example 1
status.measurement.buffer_available.enable =
status.measurement.buffer_available.SMUA
Uses the constant to set the SMUA bit of the measurement event buffer available summary enable register.
Example 2
status.measurement.buffer_available.enable = 2
Uses the decimal value to set the SMUA bit of the measurement event buffer available summary enable
register.
Also see
Measurement event registers (on page 15-7)
status.measurement.current_limit.*
This attribute contains the measurement event current limit summary registers.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
2 (All bits set)
